Rotary Label Shrink Packaging Machine
SF-1230R Semi-Automatic Label Shrink Packaging Machine is primarily designed for label shrinking on bottle-shaped, can-shaped, barrel-shaped, and cup-shaped products. It can perform shrinking on bottle necks, bottle bodies, bottle bases, and entire products.
  • SF-1230R Semi-Automatic Label Shrink Packaging Machine
    is mainly designed for label shrinking on bottle-shaped, can-shaped,
    barrel-shaped, and cup-shaped products. It can perform shrinking on
    bottle necks, bodies, bases, and entire products.

  • The conveyor speed is controlled by a frequency converter for stepless adjustment.

  • The shrinking temperature is intelligently controlled by a digital temperature controller, ensuring stable conveyance.

  • The
    clamping positions on the conveyor belt can be arbitrarily adjusted to
    accommodate different sizes without the need for mold changes.

  • Rotary clamping positions ensure even heating of bottles, resulting in better shrinking effects.

  • Equipped with a dual-circulation hot air system.

  • Widely used in industries such as food, pharmaceuticals, and cosmetics.


Model

SF-1230RSF-2040R

Power

12 kw12 kw

Power Supply

AC220V/3803PH 50/60HzAC220V/3803PH 50/60Hz

Maximum Packaging Dimensions

100×280mm180×380mm

Workbench Height

1250×120×300mm1250×200×400mm

Packaging Speed

20-40m/min20-40m/min

Shrink Film

PET/PVCPET/PVC

Machine Dimensions

2640×440×1400mm2640×540×1500mm

Workbench Height

520±50mm520±50mm

Gross/Net Weight

220/180kgs250/230kgs

Air Temperature

0-300℃0-300℃
